Indoor P4 SMD Main Parameter
| Item | Parameter |
|---|---|
| Model Number | P4–16S |
| Module size | 256mm*128mm |
| Pixel pitch | 4mm |
| Pixels Density | 62500 dots/m² |
| Pixel configuration | 1R1G1B |
| Package mode | SMD2121 |
| Pixel resolution | 64dots(W) * 32 dots(H) |
| Drive type | Constant drive |
| Scan mode | 1/16 scan |
| Port type | HUB75 |
| Brightness of white balance | ≥2000cd/m² |
| Best viewing distance | 4M~20M |
| Best viewing angle | 160° (W) 120° (H) |
| Temperature | storage:-35℃~+85℃ working:-20℃~+50℃ |
| Operation humidity | 10%~95% |
| Thickness | 85mm |
| Working voltage | AC220V ±10% |
| Average Power consumption | 600W/㎡ |
