Outdoor P10 SMD Main Parameter
| Item | Parameter |
|---|---|
| Model Number | P10-4S |
| Module size | 320mm*160mm |
| Pixel pitch | 10mm |
| Pixels Density | 10000 dots/m² |
| Pixel configuration | 1R1G1B |
| Package mode | SMD3535 |
| Pixel resolution | 32dots(W)*16dots(H) |
| Drive type | Constant drive (MBI5124/2038s) |
| Scan mode | 1/4scan |
| Port type | HUB75 |
| Brightness of white balance | ≥7500cd/m² |
| Best viewing distance | ≥10m |
| Best viewing angle | 160°(W) 120°(H) |
| Temperature | Storage: -35℃ ~ +85℃ Working: -20℃ ~ +50℃ |
| Operation humidity | 10%~95% |
| Thickness | 80mm |
| Working voltage | AC220V±10% |
| Average Power consumption | 210W/m² |
